Samurai Paintbrush stand

-

Another request, one of the reward levels for a kickstarter paintbrush project was a samurai style paintbrush stand. They're not available for purchase yet and this one is required before they will make it to the shops so I was asked if I could laser something suitably similar. I came up with this version that clicks together to hold it in place, but is otherwise the same. I'm now off to cut it in 6mm walnut. (svg here)
