Hinged Pumpkin Box 3

-


I wanted these boxes to be coloured rather than plain wood so I reached for the acrylic paints and mixed up a nice shade of orange paint for them. The colour came out nice with some good coverage and uniform all over so I scrapped some off again before it had set. The results speak for themselves and I'm really happy with the textured style for the panels. I made sure to align the streaks vertically on the sides of the box during cutting.
