Saxon Shield

-

To go with the saxon helmet we made a super simple shield. It's literally just a circle of 3mm birch with a handle cut through the middle. I had a vacuum formed shield boss left over from the roman shield we made previously. The details were just drawn on with low power lines which made it easy for Eli to paint. He even got to wear my chain mail shirt to finish the look off.
